3003 Aluminium Strip

Online Inquiry

Aluminum strip foil

Grade :1050,1060,1070, 1350,3003,3105,5005,5052,6061,6082,8011
Thickness :0.18mm-4.5mm
Width :15mm-2000mm
Internal dianeter :300mm 400mm 500mm

3003 aluminum strip belongs to the 3000 series of aluminum alloys, known for its excellent corrosion resistance, formability, and weldability. It is a non-heat-treatable alloy primarily composed of aluminum and manganese. The addition of manganese enhances the alloy's strength and corrosion resistance.

3003 Aluminum Strip Chemical Composition

Aluminum (Al): 98.6%

Manganese (Mn): 1.2-1.8%

Iron (Fe): 0.7%

Copper (Cu): 0.05-0.20%

Zinc (Zn): 0.1%

Others (each): 0.05%

Others (total): 0.15%

Common Applications of 3003 Aluminum Strips

3003 Aluminum Strip for Electrical Industry ,Width: 20-100mmTemper: O (Annealed), Specifications: ASTM B209, EN 485,Example: Electrical connectors, small components in electronic devices.

3003 Aluminum Strip for Automotive Trim, Width: 100-300mmTemper: H14, H16, Specifications: AMS 4008, ASTM B209,
Example: Trim strips, decorative elements in automotive interiors.,

3003 Aluminum Strip for Roofing and Cladding, Width: 300-600mmTemper: H24 Specifications: ASTM B209, EN 573
Example: Roofing panels, architectural components.

3003 Aluminum Strip for Heat Exchanger Fins,Width: 600-1200mmTemper: H16, H18,Specifications: AMS 4008, ASTM B209,Example: Fins for heat exchangers, evaporator coils.

3003 Aluminum Strip for Building Facades,Width: 1200+mmTemper: H18,Specifications: AMS 4008, ASTM B209
Example: Large structural components, building facades.
